ABB REF 542plus User Manual

21
5. Changing the language displayed
The international HMI version V5 can support up to two different languages. The
first one can be used to display the local language. Due to the high QVGA
resolution, it is possible to display, for example, Chinese on the HMI. Then the
second language becomes English. If no local language is defined, the language
used is always English, which is the default one.
A060408
Fig. 5.-1 Display of Chinese as first language
The following Fig. 5.-2 shows how to change the active language on the HMI. The
prerequisite is that there is a local language defined. Do as follows:
*
Go to the main menu by pressing MENU .
*
Press UP and DOWN simultaneously to get to the Language page.
*
Press ENTER to execute the language change.
Multifunction Protection and Switchgear Control Unit
Operator's manual
REF 542plusREF 542plus
1MRS755869
