ABB RELION RET670 User Manual

1.3.3 Related documents
GUID-94E8A5CA-BE1B-45AF-81E7-5A41D34EE112 v5
Documents related to RET670 Document numbers
Application manual 1MRK 504 163-UUS
Commissioning manual 1MRK 504 165-UUS
Product guide 1MRK 504 166-BEN
Technical manual 1MRK 504 164-UUS
Type test certificate 1MRK 504 166-TUS
670 series manuals Document numbers
Operation manual 1MRK 500 127-UUS
Engineering manual 1MRK 511 398-UUS
Installation manual 1MRK 514 026-UUS
Communication protocol manual, DNP3 1MRK 511 391-UUS
Communication protocol manual, IEC 61850
Edition 2
1MRK 511 393-UEN
Point list manual, DNP3 1MRK 511 397-UUS
Accessories guide 1MRK 514 012-BUS
Connection and Installation components 1MRK 513 003-BEN
Test system, COMBITEST 1MRK 512 001-BEN
1.4 Document symbols and conventions
1.4.1 Symbols
GUID-2945B229-DAB0-4F15-8A0E-B9CF0C2C7B15 v12
The electrical warning icon indicates the presence of a hazard which
could result in electrical shock.
The warning icon indicates the presence of a hazard which could result
in personal injury.
The caution hot surface icon indicates important information or
warning about the temperature of product surfaces.
Section 1 1MRK 504 163-UUS A
Introduction
30 Transformer protection RET670 2.2 ANSI
Application manual

ABB RELION RET670 Specifications

General

Rated Frequency	50/60 Hz
Communication Protocols	IEC 61850, IEC 60870-5-103, DNP3
Operating Temperature Range	-25°C to +55°C
Mounting	Rack Mounting
Input Voltage	100-240 V AC
Protection Functions	Overcurrent Protection
Enclosure	IP20
