ABB RELION RET670 User Manual

20.2 Redundant communication
20.2.1 Identification
GUID-B7AE0374-0336-42B8-90AF-3AE1C79A4116 v1
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
IEC 62439-3 Parallel redundancy
protocol
PRP - -
IEC 62439-3 High-availability seamless
redundancy
HSR - -
Access point diagnostic for redundant
Ethernet ports
RCHLCCH - -
20.2.2 Application
GUID-172BA5D7-6532-4B0D-8C1D-2E02F70B4FCB v1
Dynamic access point diagnostic (RCHLCCH) is used to supervise and assure
redundant Ethernet communication over two channels. This will secure data transfer
even though one communication channel might not be available for some reason
Parallel Redundancy Protocol (PRP) and High-availability Seamless Redundancy
(HSR) provides redundant communication over station bus running the available
communication protocols. The redundant communication uses two Ethernet ports.
1MRK 504 163-UUS A Section 20
Ethernet-based communication
Transformer protection RET670 2.2 ANSI 925
Application manual

ABB RELION RET670 Specifications

General

Rated Frequency	50/60 Hz
Communication Protocols	IEC 61850, IEC 60870-5-103, DNP3
Operating Temperature Range	-25°C to +55°C
Mounting	Rack Mounting
Input Voltage	100-240 V AC
Protection Functions	Overcurrent Protection
Enclosure	IP20
