Chapter 3 107
Replacing the LCD/LED Panel
1. Place the LCD panel in the LCD cover.
2. Run the cable along the guide in the LCD cover as shown.
3. Replace the four (4) securing screws to the LCD panel.
Step Size Quantity Screw Type
LCD/LED Panel M2.5*5 4
