Acer ASPIRE 5252 Service Guide

Chapter 3 143
Replacing the ODD Module
1. Press the bezel into the tray, bottom edge first, to secure it to the ODD module.
2. Place the bracket on the ODD module.
3. Secure the ODD bracket with the two (2) screws.
Step Size Quantity Screw Type
ODD Bracket M2*3 2
