60 Chapter 3
Removing the HDD Module
1. See “Removing the Logic Lower Door” on page 55.
2. Using plastic tweezers lift the pull tab from the chassis.
3. Using the pull-tab, slide the HDD module in the direction of the arrow to disconnect the interface.
4. Lift the HDD module clear of the HDD bay.
NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it.
