Chapter 3 89
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
LCD Bezel M2.5*6 2 86.R4F02.003
Inverter Board
(LCD Only)
M2.5*5 1 86.R4F02.001
LCD/LED Panel M2.5*5 4 86.R4F02.001
LCD Brackets M2*3 6 86.R4F02.007
Remove
LCD/LED Panel
Remove
LCD Bezel
Remove
LVDS Cable
Remove LCD
Module from Main
Unit before
proceeding
Remove
LCD Brackets
Remove
Antennas
Remove
Camera Module
Remove
Inverter Board
(LCD Only)
Remove
Microphone
Cable
To Next Page
