Acer Aspire E1-421 User Manual

Machine Maintenance Procedures 3-15
WLAN (Wireless Local Area Network) Module Removal 0
Prerequisite:
Base Door Removal
1. Find WLAN module (B) on the base assembly. Refer to Figure 3-11.
Figure 3-11. Component Location
2. Disconnect WLAN antenna (C) connected to WLAN card (Figure 3-12).
3. Remove one (1) screw (A) securing the WLAN module in place (Figure 3-12).
Figure 3-12. WLAN Module
A
B
C
A
C
