Acer Aspire E1-421 User Manual

3-74 Machine Maintenance Procedures
Replacing the ODD (Optical Disk Drive) Module 0
1. Install ODD bezel (B) on ODD module (Figure 3-87).
Figure 3-87. ODD Bracket
2. Install ODD bracket (D) on ODD module (Figure 3-87).
3. Install and secure two (2) screws (C) to secure the bracket (D) to the back of ODD
(Figure 3-87).
4. Install ODD module into ODD bay (Figure 3-88).
Figure 3-88. ODD Module
5. Secure one (1) screw (A) to the ODD mudule (Figure 3-88).
D
B
C
C
B
A
