Machine Maintenance Procedures 3-7
Disassembly Process 0
The disassembly process is divided into the following sections:
External components disassembly
Main unit disassembly
LCD module disassembly
The flowcharts provided in the succeeding disasembly sections illustrate the entire
disassembly sequence. Observe the order of the sequence to avoid damage to any of the
hardware components. For example, when removing the mainboard, remove first the
keyboard, and the LCD module then disassemble the inside assembly frame in that
order.
Table 3-1. Main Screw List
Size Quantity Acer Part No.
M3.0*3.5 (NI) 4 86.WFB07.001
M2.5*6 23 86.A08V7.004
M2.5*4 15 86.A08V7.014
M2*3 12 86.SA107.001
M2*2 4 86.W4107.002
