Acer Aspire E1-421 User Manual

3-28 Machine Maintenance Procedures
Speaker Module Removal 0
Prerequisite:
Mainboard Removal
1. Find Speaker Module (A) on the base assembly as shown on Figure 3-27.
2. Remove four (4) screws (B) securing the speaker module in place (Figure 3-27).
Figure 3-27. Speaker Module
3. Lift up the Right Speaker upwards from the base assembly as shown in Figure 3-28.
4. Gentely remove the speaker cable (C) from the cable guides (Figure 3-28).
Figure 3-28. Speaker Cable
5. Remove Speaker Module (A) from the base assembly.
A
B
B
C
D
