1-36 Hardware Specifications and Configurations
LAN Interface
Bluetooth Interface (not available in this model)
Bluetooth Module (not abailable in this model)
Wireless Module 802.11 b/g/n
Item Specification
LAN chipset Atheros 8151L-B
LAN connector type RJ45
LAN connector location RJ45 port at the left side
Features
Support 10/100/1000 Mbps Ethernet Controller
Support remote wake-up (including AMD Magic packet
and MS Wake-up frame) in both ACPI and APM
Max payload size 128 bytes, read request size 4096 bytes
Item Specifications
Chipset
Data throughput
Protocol
Interface
Connector type
Supported protocol
Item Specifications
Model
Feature
Item Specification
Chipset BCM 4313 Atheros AR9485 Realtek
RTL8188CE-VL
Data throughput 11-54 Mbps, up to
72.2 Mbps for Draft-N
11-54 Mbps, up to 150
Mbps
11-54 Mbps, up to 150
Mbps
Protocol b, g, n b, g, n b, g, n
Interface PCI-Express half mini card
