Jumper and Connector Locatio
ns
5-3
Jumper and Connector Locations
Mainboard Jumper and Connector Locations
0
Figure 5-1.
Mainboard Top
Table 5-1.
Mainboard Top
Item
Description
Item
Description
1
LVDS Connector
4
Bluetoot
h Connector
2
Cardreader Connector
5
Touchpad Conn
ector
3
USB Connector
6
Keyboard Connector
6
5
4
3
2
1
190
192
