Machine Maintenance Procedures 3-35
DC-in Jack Removal 0
Prerequisite:
LCD (Liquid Crystal Display) Module Removal
1. Find DC-in Jack Module (A) on the base assembly. Refer to Figure 3-34.
2. Remove DC-in Jack Module (A) from the base assembly.
Figure 3-34. DC-in Jack Module
A
