3-16 Machine Maintenance Procedures

WLAN (Wireless Local Area Network) Module Removal 0

Prerequisite:

Base Door Removal

1. Find WLAN module (B) on the base assembly. Refer to Figure 3-11.

Figure 3-11. Component Location

2. Disconnect WLAN antenna (C) connected to WLAN card (Figure 3-12).

3. Remove one (1) screw (A) securing the WLAN module in place (Figure 3-12).

Figure 3-12. WLAN Module
