Machine Maintenance Procedures 3-21

Upper Case Removal 0

Prerequisite:

Keyboard Removal and Base Door Removal

1. Remove eighteen (18) screws from the base assembly (Figure 3-18).

Figure 3-18. Upper Case Screws Location

2. Disconnect touchpad FPC (A) from mainboard connector (B) (Figure 3-19).

3. Remove two (2) screws (C) securing the upper case in place (Figure 3-19).

Figure 3-19. Touchpad FPC
