Machine Maintenance Procedures 3-33
Thermal Module Installation 0
Apply approved thermal grease and ensure all heat pads are in position
before replacing module.
Use caution when applying thermal grease. Thermal grease may cause
damage to the mainboard.
The following thermal grease types are approved for use:
Silmore GP50
Honeywell
Jet Motor 7762
The following thermal pads are approved for use:
Eapus XR-PE
1. Remove all traces of thermal grease from CPU using a lint-free cloth or cotton swab
and Isopropyl Alcohol, Acetone, or other approved cleaning agent.
2. Apply small amount of thermal grease to center of CPU.
Force used during installation of thermal module is sufficient to spread grease
evenly over CPU top.
3. Place the thermal module (C) on the mainboard. Refer to Figure 3-29.
4. Tighten four (4) captive screws (A) in numerical order from one (1) to four (4) to
mainboard (Figure 3-31). Ensure the thermal module is properly aligned and seated.
5. Connect the thermal fan cable to mainboard connector (B) (Figure 3-31).
6. Install Mainboard.
