3-28 Machine Maintenance Procedures

Speaker Module Removal 0

Prerequisite:

Mainboard Removal

1. Find Speaker Module (A) on the base assembly as shown on Figure 3-27.

2. Remove four (4) screws (B) securing the speaker module in place (Figure 3-27).

Figure 3-27. Speaker Module

3. Lift up the Right Speaker upwards from the base assembly as shown in Figure 3-28.

4. Gentely remove the speaker cable (B) from the cable guides (Figure 3-28).

Figure 3-28. Speaker Cable

5. Remove Speaker Module (A) from the base assembly.
