Machine Maintenance Procedures 3-29

Speaker Module Installation 0

1. Place the Left Speaker (D) onto base assembly. Refer to Figure 3-28.

2. Install and secure two (2) screws (B) to the left speaker. Refer to Figure 3-27.

3. Secure the speaker cable to the cable guides from left to right (Figure 3-28).

4. Place the Right Speaker onto base assembly. Refer to Figure 3-28.

5. Install and secure two (2) screws (B) to the right speaker (Figure 3-27).

6. Install Mainboard.

ID Size Quantity Screw Type

B M2*2 4
