2.11 Steering and front wheels
2.11.1 steering
Regularly check the steering for:
• Leaks and damage
• Perfect condition of the sealing bellows and hose lines
• Chafing points
2.11.2 Check the toe-in
Setting value
• Toe-in is 0 +2 mm.
Setting conditions
• Steering and suspension in center position.
• Front axle loaded normally.
• Measure distance between tires on the wheel
hub at the front rim flange (A).
• Push tractor forward by 1/2 turn of the front
wheels.
• Measure distance between tires on the wheel
hub at the rear rim flange (A +2).
IMPORTANT:
Observe the air pressure recommended by the tire
manufacturer.
Fig. 63
2. Service and maintenance
54 Maintenance
530.020.020.011 Rev.A
