Agilent Technologies 8156A User Manual

168
Specifications
Specifications
•
[2]
Includes insertion loss of two HMS-10 connectors. Typical
variation over temperature range <0.3dBpp.
•
[3]
Measured at constant temperature.
•
[4]
With narrow linewidth lasers, such as DFB lasers, power
fluctuations up to 0.2dBpp may occur.
Table C-2 Monitor Output Options
•
[1]
Typical, depends on performance of external connector
•
[2]
Includes insertion loss of two HMS-10 connectors. Typical
variation over temperature range <0.3dBpp.
•
[3]
Measured at constant temperature.
Option 121 Option 221
High
Performance
High Return
Loss
Wavelength Range 1200 - 1650nm
Attenuation Range 60dB (excluding insertion loss)
Fiber Type 9/125
µm single-mode
Connector Type straight contact angled contact
Return Loss
[1]
>45dB >60dB
Insertion Loss (typ)
[2]
3.3dB
Attenuation Accuracy (linearity)
[3]
typical
<
±0.1dB
<
±0.05dB
Repeatability
typical
<
±0.01dB
<
±0.005dB
Polarization Dependent Loss
typical
<0.1dBpp
<0.03dBpp
Polarization Mode Dispersion 6fs
Monitor Output (typ.) 13dB tap (1:20)
Useful Back-Reflection Range 6.6 to 45dB 6.6 to 60dB
