Agilent Technologies 8156A User Manual

58
Using your Attenuator
as a Variable Back
Reflector
This chapter describes how you can use your attenuator as a
variable back reflector. An example using the back reflector kit
(option 203 with option 201) is given at the end of the chapter.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Agilent Technologies 8156A Specifications

General

Type	Optical Attenuator
Accuracy	±0.5 dB
Resolution	0.01 dB
Display	LCD
Interface	GPIB, RS-232
Attenuation Range	0 to 60 dB
Power Supply	100-240 V, 50/60 Hz
Optical Connector	FC, SC
Insertion Loss	<0.5 dB
Return Loss	> 55 dB
Connector Type	FC
