Chapter 1 11
Signal Generator Overview
Front Panel
8. Trigger
This key initiates an immediate trigger event for a function such as a list, step, or ramp sweep
(Option 007 only). Before this hardkey can be used to initiate a trigger event, the trigger mode must
be set to
Trigger Key. For example: press the Sweep/List hardkey, then one of the following sequences of
softkeys:
•
More (1 of 2) > Sweep Trigger > Trigger Key
• More (1 of 2) > Point Trigger > Trigger Key
9. MENUS
These keys open softkey menus for configuring various functions. For descriptions, see the Agilent
PSG Signal Generators Key Reference.
NOTE Some menus are optional. Refer to “Options” on page 6 for more information.
10. Help
Pressing this hardkey causes a short description of any hardkey or softkey to be displayed and, in
most cases, a listing of related remote–operation SCPI commands. There are two help modes available
on the signal generator: single and continuous. The single mode is the factory preset condition.
Toggle between single and continuous mode by pressing
Utility > Instrument Info/Help Mode > Help Mode Single Cont.
• In single mode, help text is provided for the next key you press without activating the key’s
function. Any key pressed afterward exits the help mode and its function is activated.
• In continuous mode, help text is provided for each subsequent key press until you press the
Help
hardkey again or change to single mode. In addition, each key is active, meaning that the key
function is executed (except for the Preset key).
11. EXT 1 INPUT
This female BNC input connector (functional only with Options UNT, UNU, or UNW or on the
E8663D) accepts a ±1 V
p
signal for AM, FM, and ΦM. For these modulations, ±1 V
p
produces the
indicated deviation or depth. When ac–coupled inputs are selected for AM, FM, or ΦM and the peak
input voltage differs from 1 V
p
by more than 3 percent, the HI/LO display annunciators light. The
input impedance is selectable as either 50 or 600 ohms; the damage levels are 5 V
rms
and 10 V
p
. On
signal generators with Option 1EM, this connector is located on the rear panel.
Table 1-2 Hardkeys in Front Panel MENUS Group
E8257D and E8663D
PSG Analog
E8267D PSG Vector
AM
Sweep/List
FM/ΦM
Utility
Pulse
LF Out
Mode
Mux
AM
Sweep/List
Mode Setup
Aux Fctn
FM/ΦM
Utility
I/Q
Pulse
LF Out
