Chassis and Power Supplies OmniSwitch 6900 Chassis
OmniSwitch 6900 Hardware Users Guide June 2020 page 3-7
OS6900-X72 Chassis Specifications
Note. For OS6900-X20 and OS6900-X40 chassis specifications, please refer to page page 3-4. For
OS6900-T20 and OS6900-T40 chassis specifications, please refer to page page 3-10. For OS6900-Q32
chassis specification, please refer to page page 3-14.
1
Fully populated weights include fan tray, all installable power supplies and expansion modules. These
figures do not include transceivers.
2
Maximum power consumption under full L2 traffic load includes fan tray, two power supplies and
transceivers; no expansion plug-in modules.
*Note On Chassis Versus Ambient Temperatures. Chassis temperature refers to the sensor reading of
the internal switch temperature (threshold or danger). Ambient temperature refers to the approximate room
temperature. The ambient temperature will typically be lower than the chassis temperature. Due to
different airflow characteristics, chassis temperatures will vary by model.
Chassis Width 43.3 cm (17.06 inches)
Chassis Height 4.4 cm (1.73 inches or 1RU)
Overall Chassis Depth 55.9 cm (22 inches)
Chassis Weight 7.78 kg (17.15 lb)
Chassis Weight (fully populated)
1
10.86 kg (23.95 lb)
Power Supply Bays 2
Maximum number of 40G QSFP+ ports 6
Maximum number of 10G ports (48 fixed 10G plus an additional
24 using 4X10G splitter cables at QSFP+ ports)
72
Power Consumption
2
242 W
Operating Temperature (Tmra)
OS6900-X72-F (front-to-rear airflow)
OS6900-X72-R (rear-to-front airflow)
0°C to 45°C (32°F to 113°F)
0°C to 45°C (32°F to 113°F)
Storage Temperature -10°C to 70°C (14°F to 158°F)
Operating Humidity 5% to 95% non-condensing
Storage Humidity 5% to 95% non-condensing
