Chassis and Power Supplies Power Supplies
OmniSwitch 6900 Hardware Users Guide June 2020 page 3-49
OS6900-T48C6/X48C6 AC Power Supply
AC Power Supply Front Panel
AC Power Supply LED States
Model OS6900-T48C6/OS6900-X48C6-PS-A-F, Front-to-Rear
OS6900-T48C6/OS6900-X48C6-PS-A-R, Rear-to-Front
Product Compatibility OS6900-T48C6, OS6900-X48C6
Total DC Output 400 Watts
AC Input 100–240VAC, 50-60Hz, 6–3A
DC Output 12VDC @ 33.34A
Airflow This power supply is available in either a front-to-rear or
rear-to-front model.
Notes: Do not mix OS6900-T48C6/X48C6 power supplies with
OS6900-V72/C32 power supplies.
LED State Description
Solid Green The power supply is operating normally and providing power to the
chassis
Solid Red Power supply failure
Off No AC power.
Status LED
AC Connector
Handle
Air Vent
Lock Tab
AC Power Cord
