Chapter 1 8720MC-RPS Regenerative Power Supply Overview
Catalog Number Explanation
8720MC-RPS units can be in parallel configurations with up to three units,
however, the units must be of the same size (catalog number) and series.
Table 1 - 8720MC-RPS Unit Catalog Numbers
Table 2 - 8720MC-RPS Accessory Catalog Numbers
8720MC-RPS Cat. No. Units Input Voltage
Power Rating
(single unit)
Power Rating
(1)
(2 parallel units)
Power Rating
(1)
(3 parallel units)
8720MC-RPS
Accessory Options
8720MC-RPS065BM
Leader
324…506V AC rms
Three-phase
37 kW
75 kW 110 kW
Includes 8720MC-RPS065 unit only.
8720MC-RPS065BM-HV2
Includes 8720MC-RPS065 unit plus:
• 8720MC-HF-B2 harmonic filter
• 8720MC-VA-B varistor
8720MC-RPS065BS Follower N/A N/A N/A
8720MC-RPS190BM Leader
324…506V AC rms
Three-phase
125 kW
250 kW 375 kW
Required accessories:
• 8720MC-EF190-VB line filter
• Two 8720MC-LR10-100B line reactors
8720MC-RPS190BS Follower N/A N/A N/A
(1) Leader and follower units in the same configuration must be of the same size and series. You cannot mix units of catalog number 8720MC-RPS065 with 8720MC-RPS190 and you cannot mix units of
series # with series B.
Accessory Cat. No. Accessory Use in Applications With
8720MC-EF190-VB
EMC line filter
(required for CE)
Includes:
• AC line filter
•Magnetic contactor
•Harmonic filter
•Varistor
8720MC-RPS190BM
8720MC-RFI80
EMC line filter
(required for CE)
8720MC-RPS065BM
8720MC-LR03-032B
Line reactor
8720MC-RPS065BM
8720MC-LR05-48B
8720MC-LR10-62B
8720MC-LR14-70B
8720MC-LR10-100B
(1)
(1) Order two 8720MC-LR10-100B line reactors and wire in parallel for 200 A rating when used with the 8720MC-RPS190BM units.
8720MC-RPS190BM
8720MC-HF-B2 Harmonic filter
8720MC-RPS065BM
8720MC-VA-B Varistor
