Rockwell Automation Publication 8720MC-RM001K-EN-P - September 2018 75
8720MC-RPS Startup and Operation Chapter 6
Keypad
The keypad has five push-button switches that are used to select monitoring
items, to set parameters, and to reset faults.
Press
or to perform the following tasks:
• Select monitoring items in Monitor mode
• Select parameters and move through the error log in Program mode
• Increase or decrease a numeric value when a parameter value is displayed
• Hold down
or to increase the scroll speed.
Press ENT to perform the following tasks:
• Display a selected parameter value and the contents of the error log in
Program mode
• Save a parameter value when the parameter value is displayed
Press PRG to perform the following tasks:
• Toggle between Program and Monitor modes. The PROGRAM status
indicator is OFF when operation panel is in Monitor mode and ON
when operation panel is in Program mode
• Return to the display of parameter number without saving a parameter
value when a parameter value is displayed
Press RST to reset a fault when the fault occurred and the display shows the
error code.
IMPORTANT Before resetting faults, remove the problem that caused the fault. When the
RUN sequence signal has been entered, the fault cannot be reset.
