Chapter 4 Connector Data and Feature Descriptions
Terminal Block Pinouts for 8720MC-RPS190 Units
The 8720MC-RPS190 has two terminal blocks for control power
connections.
Table 9 - Control Power Terminal Connections
Table 10 - Control Terminal Connections
TB2 Description Terminals
L1 AUX
Three-phase AC input power to the control circuit. Control PowerL2 AUX
L3 AUX
PR1
Precharge/discharge jumper:
• For internal resistor, apply jumper between
PR2-PR3 and PR5-PR6
• For external resistor, apply jumper between
PR1-PR2 and PR4-PR5
• For power regeneration mode only, remove jumper
Precharge/Discharge Resistor
PR2
PR3
PR4
PR5
PR6
MC1
Mains magnetic contactor
(rated for 250V AC/1 Amp or 30V DC/1 Amp).
Mains Magnetic Contactor
MC2
TB4 Description Terminals
+24V3
AC power to fan for the AC reactor unit through the EM4000
EMC filter unit.
AC Reactor Fan Power
0V3
SENS To enter fault signal of the fan for the AC reactor unit. Fan Fault
+24V2
Power to the main magnetic contactor and the fan for the
cabinet fan through the 8720MC-EF190 EMC filter unit.
Main Magnetic Contactor (MC)
and Optional Fan
0V2
MC1
Mains magnetic contactor
(rated for 250V AC/1 Amp or 30V DC/1 Amp).
Mains Magnetic Contactor
MC2
