Allen-Bradley MicroLogix 1100 User Manual

153 Publication 1763-UM001E-EN-P - June 2015
Appendix A
Specifications
General Specifications
Description 1763-
L16AWA L16BWA L16BBB L16DWD
Dimensions Height: 90 mm (3.5 in.), 1
04 mm (4.09 in.) (with DIN latch o pen)
Width: 110 mm (4.33 in.), Depth: 87 mm (3.43 in.)
Shipping weight 0.9 kg (2.0 lbs)
Number of I/O 12 inputs (10 digital and 2 analog) and 6 outputs
Power supply voltage 100…240V AC ( -15%, +10%)
at 47…63 Hz
24V DC ( -15%, +10%)
Class 2 SELV
12V to 24V DC ( -15%,
+10%) Class 2 SELV
Heat dissipation See Appendix G.
Power supply inrush current
(max.)
120V AC: 25 A for 8 ms
240V AC: 40 A for 4 ms
24V DC: 15 A for 20 ms
Maximum power
consumption
46 VA 52 VA 35 W
See MicroLogix 1100 DC Input Power Requirements
for 1763-L16BBB Unit on page 155.
24V DC sensor power None 250 mA at 24V DC
AC Ripple < 500 mV
peak-to-peak
400 µF max.
None
Input circuit type Digital: 120V AC
Analog: 0…10V DC
Digital: 24V DC
sink/source
(standard and high-speed)
Analog: 0…10V DC
Digital: 24V DC
sink/source
(standard and high-speed)
Analog: 0…10V DC
Output circuit type Relay Relay Relay/FET Relay
Pilot duty rating Ordinary location – B300, R150
Hazardous location – C300, R150
Temperature, operating -20…65 °C (-4…149 °F) ambient
Temperature, storage -40…85 °C (-40…185 °F) ambient
Relative humidity 5%…95% non-condensing
Vibration Operating: 10…500 Hz, 5 g, 0.015 in. max. peak-to-peak, 2 hours each axis
Relay Operation: 1.5 g
Shock, operating 30 g; 3 pulses each direction, each axis
Relay Operation: 10 g
Shock, non-operating 50 g panel mounted (40 g DIN Rail mounted); 3 pulses each direction, each axis
Terminal screw torque 0.56
Nm (5.0 in-lb) rated
