Rockwell Automation Publication 520-TD002A-EN-E - May 2015 11
PowerFlex 527 AC Drive Specifications
Environmental Specifications
Specifications PowerFlex 527
Altitude
Without derating:
With derating:
See Current Derating Curves
on page 17 for derating guidelines.
1000 m (3300 ft) max.
Up to 4000 m (13,200 ft) max., with the exception of 600V drives at 2000 m (6600 ft) max.
Surrounding Air Temperature, max.
Without derating:
With derating:
See Current Derating Curves
on page 17 for derating guidelines.
-20...50 °C (-4...122 °F)
-20...60 °C (-4...140 °F) or -20...70 °C (-4...158 °F) with optional Control Module Fan kit.
Storage Temperature
Frame A...D:
Frame E:
-40...85 °C (-40...185 °F)
-40...70 °C (-40...158 °F)
Atmosphere:
Relative Humidity: 0...95% noncondensing
Shock:
Vibration:
Complies with IEC 60068-2-27
Complies with IEC 60068-2-6:2007
Conformal Coating: Complies with:
IEC 60721-3-3 to level 3C2 (chemical and gases only)
Surrounding Environment Pollution Degree
Pollution Degree 1 & 2: All enclosures acceptable.
Sound Pressure Level (A-weighted)
Frame A & B:
Frame C:
Frame D:
Frame E:
Measurements are taken 1 m from the drive.
Maximum 53 dBA
Maximum 57 dBA
Maximum 64 dBA
Maximum 68 dBA
Drive must not be installed in an area where the ambient atmosphere contains volatile or corrosive gas, vapors
or dust. If the drive is not going to be installed for a period of time, it must be stored in an area where it will not
be exposed to a corrosive atmosphere.
Frame
Size
Operating and Nonoperating Nonoperating (Transportation)
Force (Shock/Vibration) Mounting Type Force (Shock/Vibration) Mounting Type
A 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
B 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
C 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
D 15 g / 2 g Screw only 30 g/ 2.5 g Screw only
E 15 g / 1.5 g Screw only 30 g/ 2.5 g Screw only
