Allen-Bradley PowerFlex 527 Original Instructions

Rockwell Automation Publication 520-TD002A-EN-E - May 2015 27
PowerFlex 527 AC Drive Specifications
Fuses and Circuit Breakers for PowerFlex 527
100...120V 1-Phase Input Protection Devices – Frames A...B 200...240V 1-Phase Input Protection Devices – Frames A...B
(1) When the drive is controlling motors with lower amp ratings, refer to the drive nameplate for drive input current rating. (2) The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. See Bulletin 140M Motor Protection Circuit Breakers Application Ratings
.
(3) Bulletin 140M with adjustable current range should have the current trip set to the minimum range that the device will not trip. (4) Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 480Y/277 and 600Y/347 AC input. Not UL listed for use on 480V or 600V Delta/Delta, corner ground, or high-resistance ground systems.
Catalog No.
Output Ratings Input Ratings
Frame Size
Contactor Catalog No.
IEC (Non-UL Applications) UL Applications
Normal Duty Heavy Duty
Amps kVA
Max Amps
(1)
Fuses Circuit Breakers Fuses (Max. Rating) Circuit Breakers
HP kW HP kW Min. Rating Max. Rating 140U 140M Class / Catalog No. 140U 140M
(2)(3)(4)
25C-V2P5N104 0.5 0.4 0.5 0.4 2.5 1.3 9.6 A 100-C12 15 20 140U-D6D2-C12 140M-C2E-C10 CLASS RK5, CC, J, or T / DLS-R-20 140U-D6C2-C12 140M-C2E-C10 25C-V4P8N104 1.0 0.75 1.0 0.75 4.8 2.5 19.2 B 100-C23 25 40 140U-D6D2-C25 140M-D8E-C20 CLASS RK5, CC, J, or T / DLS-R-40 140U-D6D2-C25 140M-D8E-C20 25C-V6P0N104 1.5 1.1 1.5 1.1 6.0 3.2 24.0 B 100-C23 30 50 140U-D6D2-C30 140M-F8E-C25 CLASS RK5, CC, J, or T / DLS-R-50 140U-D6D2-C30 140M-F8E-C25 Catalog No.
Output Ratings Input Ratings
Frame Size
Contactor Catalog No.
IEC (Non-UL Applications) UL Applications
Normal Duty Heavy Duty
Amps kVA
Max Amps
(1)
Fuses Circuit Breakers Fuses (Max. Rating) Circuit Breakers
HP kW HP kW Min. Rating Max. Rating 140U 140M Class / Catalog No. 140U 140M
(2)(3)(4)
25C-A2P5N104 0.5 0.4 0.5 0.4 2.5 1.7 6.5 A 100-C09 10 15 140U-D6D2-C10 140M-C2E-C10 CLASS RK5, CC, J, or T / DLS-R-15 140U-D6D2-C10 140M-C2E-C10 25C-A2P5N114 0.5 0.4 0.5 0.4 2.5 1.7 6.5 A 100-C09 10 15 140U-D6D2-C10 140M-C2E-C10 CLASS RK5, CC, J, or T / DLS-R-15 140U-D6D2-C10 140M-C2E-C10 25C-A4P8N104 1.0 0.75 1.0 0.75 4.8 2.8 10.7 A 100-C12 15 25 140U-D6D2-C15 140M-C2E-C16 CLASS RK5, CC, J, or T / DLS-R-25 140U-D6D2-C15 140M-C2E-C16 25C-A4P8N114 1.0 0.75 1.0 0.75 4.8 2.8 10.7 A 100-C12 15 25 140U-D6D2-C15 140M-C2E-C16 CLASS RK5, CC, J, or T / DLS-R-25 140U-D6D2-C15 140M-C2E-C16 25C-A8P0N104 2.0 1.5 2.0 1.5 8.0 4.8 18.0 B 100-C23 25 40 140U-D6D2-C25 140M-F8E-C25 CLASS CC, J, or T / 40 140U-D6D2-C25 140M-F8E-C25 25C-A8P0N114 2.0 1.5 2.0 1.5 8.0 4.8 18.0 B 100-C23 25 40 140U-D6D2-C25 140M-F8E-C25 CLASS CC, J, or T / 40 140U-D6D2-C25 140M-F8E-C25 25C-A011N104 3.0 2.2 3.0 2.2 11.0 6.0 22.9 B 100-C37 30 50 140U-H6C2-C35 140M-F8E-C25 CLASS CC, J, or T / 50 140U-H6C2-C35 140M-F8E-C25 25C-A011N114 3.0 2.2 3.0 2.2 11.0 6.0 22.9 B 100-C37 30 50 140U-H6C2-C35 140M-F8E-C25 CLASS CC, J, or T / 50 140U-H6C2-C35 140M-F8E-C25
