PowerFlex 527 AC Drive Specifications
Fuses and Circuit Breakers for PowerFlex 527 (continued)
525...600V 3-Phase Input Protection Devices – Frames A...E
(1) Normal and Heavy duty ratings are available for drives above 15 HP / 11 kW.
(2) When the drive is controlling motors with lower amp ratings, refer to the drive nameplate for drive input current rating.
(3) The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. See Bulletin 140M Motor Protection Circuit Breakers Application Ratings
.
(4) Bulletin 140M with adjustable current range should have the current trip set to the minimum range that the device will not trip.
(5) Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 480Y/277 and 600Y/347 AC input. Not UL listed for use on 480V or 600V Delta/Delta, corner ground, or high-resistance ground systems.
(6) When used with the 140M circuit breaker, the 25C-E9P9104 must be installed in a ventilated or non-ventilated enclosure with the minimum size of 457.2 x 457.2 x 269.8 mm (18 x 18 x 10.62 in.).
Catalog No.
(1)
Output Ratings Input Ratings
Frame
Size
Contactor
Catalog No.
IEC (Non-UL Applications) UL Applications
Normal Duty Heavy Duty
Amps kVA
Max
Amps
(2)
Fuses Circuit Breakers Fuses (Max. Rating) Circuit Breakers
HP kW HP kW Min. Rating Max. Rating 140U 140M Class / Catalog No. 140U 140M
(3)(4)(5)
25C-E0P9N104 0.5 0.4 0.5 0.4 0.9 1.4 1.2 A 100-C09 3 6 140U-D6D3-B20 140M-C2E-B25 CLASS RK5, CC, J, or T / DLS-R-6 – 140M-C2E-B25
25C-E1P7N104 1.0 0.75 1.0 0.75 1.7 2.6 2.3 A 100-C09 3 6 140U-D6D3-B30 140M-C2E-B25 CLASS RK5, CC, J, or T / DLS-R-6 – 140M-C2E-B25
25C-E3P0N104 2.0 1.5 2.0 1.5 3.0 4.3 3.8 A 100-C09 6 10 140U-D6D3-B50 140M-C2E-B40 CLASS RK5, CC, J, or T / DLS-R-10 – 140M-C2E-B40
25C-E4P2N104 3.0 2.2 3.0 2.2 4.2 6.1 5.3 A 100-C09 10 15 140U-D6D3-B80 140M-C2E-B63 CLASS RK5, CC, J, or T / DLS-R-15 – 140M-D8E-B63
25C-E6P6N104 5.0 4.0 5.0 4.0 6.6 9.1 8.0 B 100-C09 10 20 140U-D6D3-C10 140M-C2E-C10 CLASS RK5, CC, J, or T / DLS-R-20 – 140M-D8E-C10
25C-E9P9N104 7.5 5.5 7.5 5.5 9.9 12.8 11.2 C 100-C16 15 25 140U-D6D3-C15 140M-C2E-C16 CLASS RK5, CC, J, or T / DLS-R-25 – 140M-D8E-C16
(6)
25C-E012N104 10.0 7.5 10.0 7.5 12.0 15.4 13.5 C 100-C23 20 30 140U-D6D3-C20 140M-C2E-C16 CLASS RK5, CC, J, or T / DLS-R-30 – 140M-D8E-C16
25C-E019N104 15.0 11.0 15.0 11.0 19.0 27.4 24.0 D 100-C30 30 50 140U-H6C3-C30 140M-F8E-C25 CLASS CC, J, or T / 50 – 140M-F8E-C25
25C-E022N104 20.0 15.0 15.0 11.0 22.0 31.2 27.3 D 100-C30 35 60 140U-H6C3-C35 140M-F8E-C32 CLASS CC, J, or T / 60 – 140M-F8E-C32
25C-E027N104 25.0 18.5 20.0 15.0 27.0 28.2 24.7 E 100-C30 35 50 140U-H6C3-C35 140M-F8E-C32 CLASS CC, J, or T / 50 – 140M-F8E-C32
25C-E032N104 30.0 22.0 25.0 18.5 32.0 33.4 29.2 E 100-C37 40 60 140U-H6C3-C50 140M-F8E-C32 CLASS CC, J, or T / 60 – 140M-F8E-C32
