PowerFlex 527 AC Drive Specifications
1.0 0.75 1.0 0.75 1.7 446...660 A 25-PM1-E1P7
2.0 1.5 2.0 1.5 3.0 446...660 A 25-PM1-E3P0
3.0 2.2 3.0 2.2 4.2 446...660 A 25-PM1-E4P2
5.0 4.0 5.0 4.0 6.6 446...660 B 25-PM1-E6P6
7.5 5.5 7.5 5.5 9.9 446...660 C 25-PM1-E9P9
10.0 7.5 10.0 7.5 12.0 446...660 C 25-PM1-E012
15.0 11.0 15.0 11.0 19.0 446...660 D 25-PM1-E019
20.0 15.0 15.0 11.0 22.0 446...660 D 25-PM1-E022
25.0 18.5 20.0 15.0 27.0 446...660 E 25-PM1-E027
30.0 22.0 25.0 18.5 32.0 446...660 E 25-PM1-E032
PowerFlex 527 Control Module
Item Description Frame Size Catalog No.
PowerFlex 527 Control Module Replacement control module for use with PowerFlex 527 drives. Includes:
• Control Module
• Control Module Front Cover
A...E 25C-CTM1
Other Parts
Item Description Frame Size Catalog No.
PowerFlex 527Control Module Front
Cover
Replacement cover for the control module I/O terminals and EtherNet/IP ports. A...E 25C-CTMFC1
PowerFlex 520-Series Power Module
Front Cover
Replacement cover for the PowerFlex 520-Series power module. B 25-PMFC-FB
C 25-PMFC-FC
D 25-PMFC-FD
E 25-PMFC-FE
PowerFlex 520-Series Power Terminal
Guard
Replacement finger guard for power terminals. A 25-PTG1-FA
B 25-PTG1-FB
C 25-PTG1-FC
D 25-PTG1-FD
E 25-PTG1-FE
PowerFlex 527 Removable Terminal
Blocks Kit
Replacement terminal blocks for control wiring. A...E 25C-RCTB
PowerFlex 527 Control Module Internal
Fan Kit
Replacement internal fan for the control module. A...E 25C-FAN2-INT
PowerFlex 520-Series Heatsink Fan Kit Replacement fan for drive power module. A 25-FAN1-FA
B25-FAN1-FB
C25-FAN1-FC
D25-FAN1-FD
E25-FAN1-FE
Bulletin 1321-3R Series Line Reactors
Output Ratings
(1)
Input Line Reactor
(2)(3)
Output Line Reactor
(2)(3)
Normal Duty Heavy Duty IP 00 (Open Style) IP 11 (NEMA/UL Type 1) IP 00 (Open Style) IP 11 (NEMA/UL Type 1)
HP kW HP kW Catalog No. Catalog No. Catalog No. Catalog No.
200...240V 50/60 Hz 3-Phase
0.5 0.4 0.5 0.4 1321-3R2-D 1321-3RA2-D 1321-3R2-D 1321-3RA2-D
1.0 0.75 1.0 0.75 1321-3R4-A 1321-3RA4-A 1321-3R4-A 1321-3RA4-A
Output Ratings
Input Voltage Range Frame Size Catalog No.
Normal Duty Heavy Duty
Output Current (A)HP kW HP kW
