Allen-Bradley PV550 User Manual

Publication 2711-UM014B-EN-P
3-18 Configuring the Terminal
Viewing Terminal
Information
Select Terminal Info from the Configuration Mode menu to display
information about your terminal. This information may be needed
when calling for technical support.
Boot
Displays the boot code revision.
Firmware
Displays the firmware revision.
Hardware
Displays the hardware configuration.
Keypad (CPS)
Touch Screen (TS)
Keypad and Touch Screen (TS CPS)
Communications Port (P#.xxx, for example, P0.485 or P1.232)
Screen Size (SS5.5, SS6.0, SS9.0, SS10.0, SS14.0)
Filename
Displays the name of the active application file. If the application file
exists but is invalid, the file name appears as ********.
• Bytes Used displays the number of bytes used by the loaded
application.
• Bytes Free displays the number of bytes available.
Font File
Displays the name of the external font file used by the application.
Exit
Returns to the Configuration Mode menu.
TERMINAL INFO
Boot:
############
Firmware:
############
Hardware:
#######################################
Filename:
Fontfile:
############
############
############
############
Bytes Used
Bytes Free
F16
EXIT
