Publication 2711-UM014B-EN-P
4-4 Using a Memory Card
Loading Application
from a Memory Card
The procedure below shows how to load an application on a memory
card into the PanelView terminal.
To load an application from a memory card:
1. Insert the memory card in the card slot of the terminal.
If the terminal does not have an application loaded, the
Configuration Mode menu appears. Skip step 2.
2. Open the Configuration Mode menu by simultaneously pressing
the Left and Right arrows (on keypad terminals), or the
Goto Config. Screen button (on touch screen terminals).
3. Select Memory Card and press the Enter
↵ key.
4. Press Memory Card Listing, [F1] on keypad terminals, until the
application file you want to load is displayed.
ATTENTION
!
Explosion Hazard - Do not install or remove memory
card unless power has been switched off or the area
is known to be non-hazardous.
Function keys do not
appear on touch
screen terminals.
