36-EN
Setting the Speaker Level
Setting item:
Speaker Level
Touch [
] or [ ] for each speaker to adjust the Speaker.
-24dB to 10dB (0.1 dB/step)
Setting Defeat
If Defeat is [On], the EQ and Equalizer setting are turned O. is
disables any settings made for these functions.
Setting item:
Defeat
Setting contents:
O (Initial setting) / On
About the Crossover
Crossover (X-Over):
is unit is equipped with an active crossover. e crossover limits
the frequencies delivered to the outputs. Each channel is controlled
independently. us, each speaker pair can be driven by the frequencies
for which they have been optimally designed.
e crossover adjusts the HPF (high pass lter) or LPF (low pass lter)
of each band.
Adjustments should be made according to the reproduction
characteristics of the speakers. Depending on the speakers, a passive
network may not be necessary. If you are unsure about this point, please
consult your authorized Alpine dealer.
25 Hz, 32Hz, 40Hz, 50Hz, 63Hz, 80Hz
Cut-o frequency
HPF
LPF
Subwoofer
(LPF)
---
25Hz, 32Hz, 40Hz, 50Hz,
63Hz, 80Hz
100Hz, 125Hz, 160Hz,
200Hz, 250Hz
Rear speaker
(HPF)
25Hz, 32Hz, 40Hz, 50Hz,
63Hz, 80Hz
100Hz, 125Hz, 160Hz,
200Hz, 250 Hz
---
Front
speaker
(HPF)
25Hz, 32Hz, 40Hz, 50Hz,
63Hz, 80Hz
100Hz, 125Hz, 160Hz,
200Hz, 250Hzz
---
•
HPF (high pass lter): Cuts the lower frequencies and allows the higher
frequencies to pass.
•
LPF (low pass lter): Cuts the higher frequencies and allows the lower
frequencies to pass.
•
Do not use a tweeter without the HPF on or set to a low frequency, as it
may cause damage to the speaker due to the low frequency content.
•
Adjustment should be made according to the recommended crossover
frequency of the connected speakers. Determine the recommended
crossover frequency of the speakers. Adjusting to a frequency range
outside that recommended may cause damage to the speakers.
For the recommended crossover frequencies of Alpine speakers, refer to
the respective Owner’s Manual.
We are not responsible for damage or malfunction of speakers caused
by using the crossover outside the recommended value.
