6 Operation of the HYC_50
Page 51 of 76
All rights reserved. Reproduction of this document, in whole or in part, is only permitted with the permission of alpitronic GmbH.
6.1.2. Charging plug selection
Now select the charging plug with which you want to charge your vehicle. Navigation is
performed by touching the respective controls on the touchscreen.
Figure 23: Charging plug selection
Information
Depending on the configuration of the charging pole, other symbols may
be displayed because other charging plugs are installed.
When the connectors are free, the corresponding LED strips light up
green.
To access the language selection, press the screen at the very bottom in
the middle.
