Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Enova DGX DXLink Twisted Pair 4K Boards* (page 82)
* Enova DXLink Twisted Pair 4K Boards must be used in conjunction with DXLink Twisted Pair 4K Transmitters and Receivers or
other AMX DXLink signal management solutions. For model numbers of compatible Transmitters and Receivers, see page 97. For
system setup information, see page 101.
Enova DGX DXLink Fiber Boards** (page 109)
** Enova DXLink Fiber Boards must be used in conjunction with DXLink Fiber Transmitters and Receivers. For model numbers of
compatible Transmitters and Receivers, see page 112. For system setup information, see page 116.
Enova DGX Expansion Boards
Enova DGX 100 Series Switchers currently support three types of expansion boards: Dante Audio Switching Boards (ASB-DAN),
Audio Switching Boards (ASB) and the Audio Insert/Extract Board (AIE).
Dante Audio Switching Boards (ASB-DAN) and Audio Switching Boards (ASB) – must be installed as an input and output
pair (or pairs), depending on the enclosure (see table below).
Audio Insert/Extract Board – can be installed in either or both of the expansion board slots for the Enova DGX 800/1600/
3200 and in any number of the expansion board slots in the Enova DGX 6400.
IMPORTANT: The Enova DGX expansion boards will not work in standard input or output board slots (standard input or output
boards will not work in expansion board slots). The two types of expansion boards are not compatible with each other and will not
work together in the same system.
Audio Switching Board (ASB-DAN and ASB) Sets*** (page 142)
*** Audio Switching Boards will not operate unless the complete board set (one or two I/O pairs, depending on model) is installed.
Enova DGX Audio Insert/Extract Board (page 154)
Type Part # Model
DXLink Twisted Pair 4K Input FG1061-570 DGX-I-DXL-4K
DXLink Twisted Pair 4K Output FG1061-580 DGX-O-DXL-4K
Type Part # Model
DXLink Multimode Fiber Input Board, Duplex FG1058-622 DGX-I-DXF-MMD
DXLink Multimode Fiber Output Board, Duplex FG1058-632 DGX-O-DXF-MMD
DXLink Single Mode Fiber Input Board, Duplex FG1058-620 DGX-I-DXF-SMD
DXLink Single Mode Fiber Output Board, Duplex FG1058-630 DGX-O-DXF-SMD
DXLink Multimode Fiber Input Board, Simplex FG1058-623 DGX-I-DXF-MMS
DXLink Multimode Fiber Output Board, Simplex FG1058-633 DGX-O-DXF-MMS
DXLink Single Mode Fiber Input Board, Simplex FG1058-621 DGX-I-DXF-SMS
DXLink Single Mode Fiber Output Board, Simplex FG1058-631 DGX-O-DXF-SMS
Type Part # Model
Audio Switching Board Set (one I/O pair)
for Enova DGX 800/1600
FG1061-716 DGX800/1600-ASB
(ENOVADGX 800/1600 AUD SWITCH BOARD KIT)
Audio Switching Board Set (one I/O pair)
for Enova DGX 3200
FG1061-732 DGX3200-ASB
(ENOVADGX 3200 AUD SWITCH BOARD KIT)
Audio Switching Board Set (two I/O pairs)
for Enova DGX 6400
FG1061-764 DGX6400-ASB
(ENOVADGX 6400 AUD SWITCH BOARD KIT)
Dante Audio Switching Board Set (one I/O
pair) for Enova DGX 800/1600/3200
FG1061-832 DGX3200-ASB-DAN
(DANTE AUD SWITCH BOARD KIT)
Dante Audio Switching Board Set (two I/O
pairs) for Enova DGX 6400
FG1061-864 DGX6400-ASB-DAN
(DANTE AUD SWITCH BOARD KIT)
Type Part # Model
Audio Insert/Extract FG1058-705 DGX-AIE
