AMX DGX800-ENC User Manual

Integrated Master – NetLinx® Programming
187
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
NetLinx Levels
NetLinx Levels
Level Ports Range Function
Input Audio
5 All A/V & ASB Inputs -24 to 24 -24 dB to 24 dB
Output Audio (Switched Audio Only)
1 All A/V & ASB Outputs 0 to 100 Output Volume
2 All A/V & ASB Outputs -20 to 20 Output Balance
31 All A/V & ASB Outputs -12 to 12 Audio EQ Band 1
32 All A/V & ASB Outputs -12 to 12 Audio EQ Band 2
33 All A/V & ASB Outputs -12 to 12 Audio EQ Band 3
34 All A/V & ASB Outputs -12 to 12 Audio EQ Band 4
35 All A/V & ASB Outputs -12 to 12 Audio EQ Band 5
36 All A/V & ASB Outputs -12 to 12 Audio EQ Band 6
37 All A/V & ASB Outputs -12 to 12 Audio EQ Band 7
38 All A/V & ASB Outputs -12 to 12 Audio EQ Band 8
39 All A/V & ASB Outputs -12 to 12 Audio EQ Band 9
40 All A/V & ASB Outputs -12 to 12 Audio EQ Band 10
DXLink TX VGA Input Video
17 DXLink TX VGA Inputs -50 to 50 Video Input Horizontal Shift
19 DXLink TX VGA Inputs -10 to 10 Video Input Vertical Shift
Output Video
20 All A/V Outputs 0 to 100 Video Output Brightness
22 All A/V Outputs 0 to 100 Video Output Contrast
Output Switching Levels
50 All A/V Outputs 0 to Max Input Video Switching: Level 50 for each output will be a value from 0 to Highest
Video Input Port indicating which video input is switched to that output.
Changing the value of this level results in a video switch.
51 All A/V & ASB Outputs 0 to Max Input Audio Switching: Level 51 for each output will be a value from 0 to Highest
Audio Input Port indicating which audio input is switched to that output.
Changing the value of this level results in a audio switch.
