Appendix A – Adding or Replacing Boards
234
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Appendix A – Adding or Replacing Boards
Applicability
This appendix covers the removal and replacement procedure for the Enova DGX input and output boards listed in the tables below.
Enova DGX input and output boards are hot-swappable, i.e., the procedure can be done while the system is powered up. The Enova
DGX Audio Switching Boards are hot-swappable. The Enova DGX AIE Boards are not hot-swappable.
Input and Output Boards
Enova DGX HDMI Boards
Enova DGX DVI Boards
Enova DGX DXLink™ Twisted Pair Boards
Enova DGX DXLink™ Twisted Pair 4K Boards
IMPORTANT: Before connecting a Solecis Digital Switcher to a DXLink Twisted Pair Input Board in an Enova DGX 100 Series Digital
Media Switcher, both the Solecis unit and all DXLink Twisted Pair boards must be upgraded with the latest available firmware versions.
Solecis units must be upgraded before connecting a unit to an upgraded input board.
DXLink Fiber Boards, Duplex and Simplex
Expansion Boards
IMPORTANT: Audio Switching Boards, Dante Audio Switching Boards, and Audio Insert/Extract Boards are not compatible. Do not
install mixed types of expansion boards in the same enclosure. If two types of boards are present, the audio subsystem is disabled.
Dante Audio Switching Board Sets
Type Part # Model
Input FG1058-540 DGX-I-HDMI
Input FG1061-540 DGX-I-HDMI-4K
Output FG1058-550 DGX-O-HDMI
Type Part # Model
Input FG1058-600 DGX-I-DVI
Output FG1058-610 DGX-O-DVI
Type Part # Model
Input FG1058-570 DGX-I-DXL
Output FG1058-580 DGX-O-DXL
Type Part # Model
Input FG1061-570 DGX-I-DXL-4K
Output FG1061-580 DGX-O-DXL-4K
Type Part # Model
Input FG1058-622 DGX-I-DXF-MMD
Output FG1058-632 DGX-O-DXF-MMD
Input FG1058-620 DGX-I-DXF-SMD
Output FG1058-630 DGX-O-DXF-SMD
Input FG1058-623 DGX-I-DXF-MMS
Output FG1058-633 DGX-O-DXF-MMS
Input FG1058-621 DGX-I-DXF-SMS
Output FG1058-631 DGX-O-DXF-SMS
Type Part # Model
Audio Switching Board Set (one each, input
and output) for Enova DGX 800/1600/3200
FG1061-832 DGX3200-ASB-DAN
(DANTE AUD SWITCH BOARD KIT)
Audio Switching Board Set (two each, input
and output) for Enova DGX 6400
FG1061-864 DGX6400-ASB-DAN
(DANTE AUD SWITCH BOARD KIT)
