Control unit
CRANKSHAFT TONE WHEEL ACQUISITION
PROCEDURE
•
Perform the cycle "Reset wheel tooth
values" with the PADS diagnostic tool;
•
Warm the engine to 80°C;
•
With the gearbox in neutral, the side
stand extended and the vehicle com-
pletely stationary, throttle up to over
8000 rpm at least three times;
•
Switch the ignition off and wait at least
one minute (Power Latch)
CAUTION
THE VEHICLE SPEED MUST BE 0 km/h THROUGHOUT
THE CRANKSHAFT TONE WHEEL ACQUISITION PROCE-
DURE.
IN CERTAIN CASES, EVEN MINOR VIBRATION PRO-
DUCED BY THE ENGINE (WITH GEARBOX IN NEUTRAL,
SIDE STAND EXTENDED AND NO SPEED READING ON
INSTRUMENT PANEL) MAY CAUSE THE PROCEDURE TO
FAIL. IN THIS CASE, THE PROCEDURE MUST BE REPEA-
TED.
RS 660 - Tuono 660 Electrical system
ELE SYS - 123

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
