CAUTION
THE CALIBRATED PAD MUST BE ASSEMBLED KEEPING
THE PRINTING OF THE THICKNESS UPWARDS.
COMPONENTS INSTALLATION
•
After lubricating the bucket tappets, the rotation seats of the camshafts and the shafts them-
selves, position them on the head. The exhaust camshaft has two grooves in the indicated
point. (lubricate with MOLYKOTE G-RAPID PLUS).
•
The correct positioning is determined by the holes, for the insertion of the pins, facing up-
wards.
•
Position the cam tower (7) complete
with fixing screws, with the exception
of the two that will subsequently fix the
upper slider.
RS 660 - Tuono 660 Maintenance
MAIN - 73

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
