RIGHT TERMINAL COVER
To remove the right side terminal cover it is nec-
essary to partially extract the right side rider foot-
peg support as described:
•
Remove the nut (3) with its washer.
•
Slightly unscrew the screw (4) without
removing it.
•
Slightly remove the swingarm pin to-
gether with the right rider footpeg sup-
port, paying attention not to drop the
spacer on the left side of the vehicle,
located between the footpeg support
and the swingarm.
•
Remove the front fixing screw (5) pay-
ing attention to collect the washer and
the bushing.
•
Remove the cover (6) from the rear to
allow it to be detached from the ex-
haust terminal at the points indicated.
MOVE THE RIGHT RIDER FOOTPEG SUPPORT
OUTWARDS TO AVOID SCRATCHING THE
TERMINAL COVER
Bodywork RS 660 - Tuono 660
BODYW - 418

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
