APRILIA RS 660 User Manual

Wheels
Front wheel
FRONT WHEEL
Pos. Description Type Quantity Torque Notes
1 Wheel axle M16 1 65 Nm (47.94 lb ft) -
2 Front brake disc flanged hex fixing
screw
M8x20 12 25 Nm (18.43 lb ft) -
Removal
To proceed with the removal of the front wheel, lift
the motorcycle using an appropriate centre stand,
remove the brake callipers and proceed as descri-
bed:
•
Loosen the screw (1) on the clamp of
the left stanchion.
Chassis RS 660 - Tuono 660
CHAS - 274

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
