After having adequately protected the
calliper, connect the brake hose, the
special screw (3) and tighten it to the
prescribed torque.
•
Fill with oil and bleed the system.
•
Check the correct functioning of the braking system
Front brake calliper
Removal
NOTE
THE FOLLOWING OPERATIONS REFER TO A SINGLE BRAKE CALLIPER BUT ARE VALID FOR
BOTH.
To remove the front brake calliper, it is necessary
to previously drain the braking system.
•
Remove the protection cap (1) of the
bleed valve and free the wiring harness
of the front ABS sensor (if present).
•
Make sure you have a container with
adequate capacity to recover the oil,
suitably protect the brake calliper and
after connecting a pipe to the breather
valve (2), unscrew it to allow the oil to
drain out and empty the system.
Braking system RS 660 - Tuono 660
BRAK SYS - 346

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
