APRILIA RS 660 User Manual

3 mm (0.1181 in)
3.02 mm (0.1189 in)
3.05 mm (0.1201 in)
3.07 mm (0.1209 in)
3.10 mm (0.1220 in)
3.12 mm (0.1228 in)
3.15 mm (0.1240 in)
Cooling system
Level check
•
Shut off the engine and wait until it
cools off.
•
Keep the vehicle upright with both
wheels on a flat surface.
•
Looking from the left side of the vehicle
through the specific opening on the in-
ternal right fairing, ensure that the liq-
uid level in the expansion tank is
between the "FULL" (maximum) and
"LOW" (minimum) marks.
WARNING
CARRY OUT THE CHECK AND TOP UP THE REFRIGER-
ANT LIQUID WITH THE ENGINE SWITCHED OFF AN COLD.
Top-up
•
From the right hand side of the motor-
cycle, remove the fastener screw (1) of
the inspection cover (2);
Maintenance RS 660 - Tuono 660
MAIN - 80

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
