APRILIA RS 660 User Manual

•
Remove the oil seal (10).
Disassembling the clutch
To remove the clutch, proceed as follows:
•
Carefully and progressively unscrew
the three screws (1) securing the thrust
plate following the order A-B-C.
CAUTION
PAY CAREFUL ATTENTION WHILE LOOSENING AND
TIGHTENING THE THREE SCREWS (1). ALWAYS PRO-
CEED GRADUALLY AND PROGRESSIVELY ON EACH
SCREW.
•
Remove the thrust plate (2).
•
Remove the three springs (3).
RS 660 - Tuono 660 Engine
ENG - 171

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
