APRILIA RS 660 User Manual

•
Place the connector on the opposite
side of the control unit and lower the
driving lever until the "click" that signals
the end of the stroke is heard.
•
When the connector is fully inserted,
the distance between the connector
and the ABS control unit must be 7.5
mm.
•
If the initial position of the connector
and of the driving lever is not as shown
in the "A1" image, the connector will
not engage properly and the measured
distance will be greater (approximately
12 mm).
•
In this case, repeat the operation as
described in the A2/A3 images.
•
We recommend creating a template in
order to ensure that the connector is
inserted correctly.
Rear brake calliper
RS 660 - Tuono 660 Braking system
BRAK SYS - 343

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
