APRILIA RS 660 User Manual

•
Drain the oil into a container having
sufficient capacity, extending the stan-
chion several times in order to ensure
the oil is drained completely.
DO NOT DISPOSE OF OIL IN THE ENVIRONMENT.
DISPOSE OF ENGINE OIL IN A SEALED CONTAINER AND
TAKE IT TO YOUR SUPPLIER OR TO THE NEAREST USED
OIL COLLECTION CENTRE.
Disassembling the fork
•
Using the special protective jaws,
block the stanchion horizontally in a
vice.
•
Extract the dust guard (12).
•
Remove the seeger ring (13) from in-
side the sleeve.
•
Pull the sleeve repeatedly towards
yourself in order to remove it from the
stanchion.
Suspensions RS 660 - Tuono 660
SUSP - 246

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
