APRILIA RS 660 User Manual

Water pump
LUBRICATION
Pos. Description Type Quantity Torque Notes
1 Oil filter - 1 15 Nm (11.06 lbf ft) -
2 Oil filter joint - 1 28.5 Nm (21.02 lbf ft) -
3 Oil pressure sensor - 1 13 Nm (9.59 lbf ft) -
4 Crankcase cap - 1 20 Nm (14.75 lbf ft) -
5 Oil pressure regulation valve - 1 42 Nm (30.98 lbf ft) -
6 Drainage plug - 1 20 Nm (14.75 lbf ft) -
7 Sump fixing flanged hex screw M6 10 12 Nm (8.85 lbf ft) -
8 Oil pump fastening screws M5 2 6 Nm (4.43 lbf ft) -
9 Oil pump gear fastener screw - 1 12 Nm (8.85 lbf ft) -
Removal
To proceed with the removal of the water pump,
proceed as described:
•
Remove the five fixing screws (1) of the
water pump cover.
Cooling system RS 660 - Tuono 660
COOL SYS - 366

APRILIA RS 660 Specifications

General

Displacement	659 cc
Bore x Stroke	81 mm x 63.93 mm
Compression Ratio	13.5:1
Maximum Power	100 HP (73.5 kW) @ 10, 500 rpm
Maximum Torque	67 Nm @ 8, 500 rpm
Transmission	6-speed
Frame	Aluminum dual beam chassis
Front Tire	120/70 ZR 17
Rear Tire	180/55 ZR 17
Seat Height	820 mm
Dry Weight	169 kg
Wet Weight	183 kg
Engine Type	Parallel twin
Fuel System	Electronic fuel injection with 48 mm throttle bodies
Front Suspension	Kayaba 41 mm upside-down fork, adjustable rebound and preload
Rear Suspension	Kayaba monoshock, adjustable rebound and preload
Front Brake	Dual 320 mm discs, Brembo radial calipers
Rear Brake	220 mm disc, Brembo caliper
ABS	Cornering ABS
Fuel Capacity	15 liters
Electronics	Ride-by-wire, multiple riding modes, traction control
